OMP Cesal 6 Electronic Extinguishing Sytem for Saloon Cars

OMP Cesal 6 Electronic Extinguishing System for Saloon Cars

The fire extinguishing system is electrically activated and specifically engineered for saloon cars, offering a compact and high-performance fire suppression solution.

The CESAL6 2KG system utilises a 2KG FK-5-1-12 and  clean agent, which is stored in a lightweight 130 mm aluminium bottle. The CESAL6 3KG system utilises a 3KG FK-5-1-12 and  clean agent, which is stored in a lightweight 160 mm aluminium bottle.

It delivers effective fire suppression through a precision-engineered nozzle and tubing layout designed to maximise performance. Included in the package are the control unit, fixing brackets, clamps, tubing, and connections.

For 2KG System:

Product Specifications:
– Suitable for saloon cars
– Extinguisher: 2KG FK-5-1-12
– Activation: Electrically activated
– Bottle dimensions: 130 mm in diameter, 197 mm in length
– Total length: 230 mm
– Total weight: 2.85 kg ±5%

Parts Included:
– 2x 8mm Aluminium piping [CD0-0323-A01]
– 1x 6mm Aluminium piping [CD0-0323-B01]
– 2x 10mm Sheath [CD0-0324-A01]
– 1x 8mm Sheath [CD0-0324-A03]
– 7x Atomizer nozzles (5 for the engine and 2 for the cockpit) [CD0-0393-A01]
– 3x 8mm T connections [CD0-0392-A02]
– 1x 6mm T connection [CD0-0392-A03]
– 2x 8mm 90° connections [CD0-0391-A02]
– 1x 6mm 90° connection [CD0-0391-A03]
– 1x Pipe reduction (6-8mm) [CD0-0399]
– 2x 8mm T connections [CD0-0390-B01]
– 1x Control unit [CD0-0398]
– 1x Control unit wiring [XMC-398-CAV]
– 1x Electric valve wiring [XMC-363-E-CAV]
– 1x Activation button [CD0-0432-A01]
– 1x Activation button protection [CD0-0441]
– 1x Bracket and clamps [CD0-0561]
– 2x Stickers [XMC-855]

For 3KG System:

Product Specifications:

– Suitable for rally cars
– Suitable for saloon cars
– 3KG FK-5-1-12 extinguisher
– Electrically activated
– 160 mm aluminium bottle
– Bottle length: 196 mm
– Total length: 229 mm
– Total weight: 3.95 kg ±5%

Parts Included:

– 2 x Aluminium piping (8 mm) [CD0-0323-A01]
– 1 x Aluminium piping (6 mm) [CD0-0323-B01]
– 2 x Sheath (10 mm) [CD0-0324-A01]
– 1 x Sheath (8 mm) [CD0-0324-A03]
– 7 x Atomizer nozzles (5 for engine and 2 for cockpit) [CD0-0393-A01]
– 3 x 8 mm T connections [CD0-0392-A02]
– 1 x 6 mm T connection [CD0-0392-A03]
– 2 x 8 mm 90° connections [CD0-0391-A02]
– 1 x 6 mm 90° connection [CD0-0391-A03]
– 1 x Pipe reduction (6-8 mm) [CD0-0399]
– 2 x 8 mm T connections [CD0-0390-B01]
– 1 x Control unit [CD0-0398]
– 1 x Control unit wiring [XMC-398-CAV]
– 1 x Electric valve wiring [XMC-363-E-CAV]
– 1 x Activation button [CD0-0432-A01]
– 1 x Activation button protection [CD0-0441]
– 1 x Bracket and clamps [CD0-0561]
– 2 x Stickers [XMC-855]

This system is designed to provide reliable fire safety for your vehicle.
